Leopard LC500-2000KV
mit Super Chief 5:1 rund
287,00 €   Stück
inkl. MwSt, zzgl. Versand

Lieferzeit: 2 - 3 Tage* 2 - 3 Tage*

Menge Stück

Leopard LC500-2000KV mit Super Chief 5:1 rund
Leistungsfähiger Antrieb für Segler bis 8000g

Daten:
Gewicht: 271g mit 4mm Goldstecker
Polzahl: 6
Motor/Getriebe Ø: 38mm
Länge: 81mm ohne Welle + Welle 22mm
Welle Ø: 6,0 mm
Lochkreis: 30mm, 3xM4 TX20
Lipo: 3-6
rpm/V: 405 gemessen mit Timing 12°
Strom max.: 90 Amp.
max. Leistung: an 11V 1000 Watt, an 14,8V 1300 Watt, an 18,5V 1650 W, an 22,2V 2000Watt
Timing: 12°
Taktfrequenz: 8-12khz

Von unserem Prüfstand:
Bestes ETA bei 14,8 Volt, 47-55 Amp. 81,4%
Bestes ETA bei 18,5 Volt, 55-70 Amp. 81,4%
Bestes ETA bei 22,2 Volt, 60-80 Amp. 81,4%
Idealer Einsatzbereich bis 5s, 50-75 Amp.

Einschaltzeiten:
Seglertypisch, unter Berücksichtigung von Aussentemperatur und wirksamer Kühlung.

Antriebsdaten im Stand:

3s - 11,1V - 20x13 GM Scale M37 4090 rpm, 45 Amp. 495 Watt, VPitch 81 km/h, Eta 81,7%
3s - 11,1V - 22x14 GM Scale M36 3911 rpm, 63 Amp. 704 Watt, VPitch 83 km/h, Eta 80,2%

4s - 14,8V - 16x10 GM Scale M38, 5644 rpm, 36 Amp. 538 Watt, VPitch 86 km/h, Eta 80,3%
4s - 14,8V - 16x13 GM Scale M38, 5473 rpm, 52 Amp. 777 Watt, VPitch 108 km/h, Eta 81,4%
4s - 14,8V - 17x10 GM Scale M38, 5609 rpm, 40 Amp. 587 Watt, VPitch 85 km/h, Eta 80,8%
4s - 14,8V - 17x13 GM Scale M38, 5437 rpm, 56 Amp. 828 Watt, VPitch 108 km/h, Eta 81,4%
4s - 14,8V - 18x10 GM Scale M38, 5520 rpm, 48 Amp. 712 Watt, VPitch 84 km/h, Eta 81,4%
4s - 14,8V - 18x13 GM Scale M38, 5350 rpm, 64 Amp. 952 Watt, VPitch 106 km/h, Eta 81,0%
4s - 14,8V - 19x10 GM Scale M38, 5485 rpm, 51,3 Amp. 760 Watt, VPitch 84 km/h, Eta 81,4%
4s - 14,8V - 19x13 GM Scale M38, 5485 rpm, 51,3 Amp. 760 Watt, VPitch 84 km/h, Eta 81,4%
4s - 14,8V - 20x13 GM Scale M37, 5266 rpm, 72 Amp. 1072 Watt, VPitch 104 km/h, Eta 80,5%

5s - 18,5V - 15x10 GM Scale M37, 7043 rpm, 43 Amp. 793 Watt, VPitch 107 km/h, Eta 79,9%
5s - 18,5V - 15x13 GM Scale M37, 6868 rpm, 58 Amp. 1075 Watt, VPitch 136 km/h, Eta 81,0%
5s - 18,5V - 16x8M Scale M37, 7051 rpm, 42 Amp. 780 Watt, VPitch 86 km/h, Eta 79,8%
5s - 18,5V - 16x10 GM Scale M38, 6923 rpm, 53 Amp. 986 Watt, VPitch 106 km/h, Eta 80,9%
5s - 18,5V - 16x13 GM Scale M38, 6661 rpm, 76 Amp. 1416 Watt, VPitch 132 km/h, Eta 80,6%
5s - 18,5V - 17x10 GM Scale M38, 6868 rpm, 58 Amp. 1075 Watt, VPitch 105 km/h, Eta 81%
5s - 18,5V - 17x13 GM Scale M38, 6607 rpm, 81 Amp. 1507 Watt, VPitch 131 km/h, Eta 80,4%
5s - 18,5V - 18x10 GM Scale VV° M38, 6732 rpm, 70 Amp. 1298 Watt, VPitch 103 km/h, Eta 80,9%
5s - 18,5V - 18x13 GM Scale VV° M38, 6480 rpm, 93 Amp. 1728 Watt, VPitch 128 km/h, Eta 79,5%
5s - 18,5V - 19x10 GM Scale VV° M38, 6681 rpm, 75 Amp. 1381 Watt, VPitch 102 km/h, Eta 80,7%


6s – 22,2V - 15x10 GM Scale M37, 8316 rpm, 59 Amp. 1300 Watt, VPitch 127 km/h, Eta 80,3%
6s – 22,2V - 15x13 GM Scale M37, 8068 rpm, 79 Amp. 1753 Watt, VPitch 160 km/h, Eta 80,5%
6s – 22,2V - 16x8 GM Scale M37, 8328 rpm, 58 Amp. 1288 Watt, VPitch 102 km/h, Eta 80,3%
6s – 22,2V - 16x10 GM Scale M38, 8145 rpm, 73 Amp. 1612 Watt, VPitch 124 km/h, Eta 80,6%
6s – 22,2V - 17x10 GM Scale VV° M38, 8068 rpm, 79 Amp. 1753 Watt, VPitch 123 km/h, Eta 80,5%
6s – 22,2V - 18x8,5 GM Scale VV° M38, 8002 rpm, 84 Amp. 1876 Watt, VPitch 104 km/h, Eta 80,3%

HINWEIS: Schubwerte gerechnet


Hinweis: Für die sichere und einfache Montage von Motor und Getriebe empfehlen wir unseren SUPER CHIEF T-Schlüssel.

Optionales Zubehör:
• 4-plus Hochleistungsfett– Link.
• T-Schlüssel für Super Chief– Link.
